1 X 8 Bare Type Optical Cable Splitter / Fiber Optic Splitter For
Fttx Systems
Decriptions
Planar lightwave circuit (PLC) splitter is a type of optical power
management device that is fabricated using silica optical waveguide
technology. It features small size, high reliability, wide
operating wavelength range and good channel-to-channel uniformity,
and is widely used in PON networks to realize optical signal power
splitting. Gezhi Photonics provides whole series of 1xN and 2xN
splitter products that are tailored for specific applications. All
products meet GR-1209-CORE-2001 and GR-1221-CORE-1999 requirements.
Features
♦ Low Insertion loss
♦ Low PDL
♦ Compact Design
♦ Good channel-to-channel uniformity
♦ Wide Operating Wavelength: From 1260nm to 1650nm
♦ Wide Operating Temperature: From -40℃ to 85℃
♦ High Reliability and Stability
Applications
♦ FTTX Systems
♦ PON Networks
♦ CATV Links
♦ Optical Signal Distribution
Compliance
♦ Telcordia GR-1209-CORE-2001
♦ Telcordia GR-1221-CORE-1999
♦ RoHS
Technical Paremeter
| Parameter | 1xN PLC Splitter Specification | ||||||
| Operating Wavelength (nm) | 1260 ~ 1650 | ||||||
| Type | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | |
| Insertion Loss (dB) | Typical | 3.6 | 6.8 | 10.0 | 13.0 | 16.0 | 19.5 |
| Max | 3.8 | 7.1 | 10.3 | 13.5 | 16.5 | 20.5 | |
| Uniformity (dB) | Typical | 0.4 | 0.5 | 0.5 | 1.0 | 1.0 | 2.5 |
| Max | 0.6 | 0.6 | 0.8 | 1.2 | 1.5 | 2.5 | |
| PDL(dB)Max | Typical | 0.1 | 0.1 | 0.1 | 0.2 | 0.2 | 0.2 |
| Max | 0.15 | 0.15 | 0.25 | 0.3 | 0.3 | 0.3 | |
Wavelength | Typical | 0.1 | 0.1 | 0.1 | 0.3 | 0.4 | 0.7 |
| Max | 0.2 | 0.3 | 0.4 | 0.6 | 0.8 | 1.0 | |
Temperature | Typical | 0.3 | 0.3 | 0.3 | 0.4 | 0.4 | 0.4 |
| Max | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | |
| Directivity (dB) Min | 55 | ||||||
| Return Loss (dB) Min | 55(50) | ||||||
| Operating Temperature (°C) | -40~ +85 | ||||||
| Storage Temperature (°C) | -40 ~ +85 | ||||||
| Fiber length | 1m or Customized | ||||||
| Fiber Type | G657A | ||||||
| Connector Type | Customized | ||||||
| PLC Splitter Bare Fiber (mm) | 4x4x40 | 4x4x40 | 4x4x40 | 4x7x50 | 4x7x50 | 4x12x60 | |
| PLC Splitter Blockless (mm) | 4x4x40 | 4x7x60 | 4x7x60 | 4x12x60 | 6x20x80 | 6x40x100 | |
| PLC Splitter Module (mm) | 100x80x10 | 100x80x10 | 100x80x10 | 120x80x18 | 120x80x18 | 141x115x18 | |
| PLC-splitter-rack-mountable(mm) | 19’1U 2U Rack-Mount Box, LGX Box, ODF Box | ||||||
Ordering information
| GP | XXX | XX | XX | XX | XX | XX |
Port | Module type | Cable type | Fiber length | Input connector | Output | |
G=Gezhi | 102=1x2 | BF=Bare Fiber | 00=none | 05=0.5m | 0=none | 0=none |
|
|
